MAX3491ESD+

Part No MAX3491ESD+
Manufacturer Maxim Integrated
Catalog Interface - Drivers, Receivers, Transceivers
Description IC TXRX RS485/422 10MBPS 14SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 50mV
Data Rate 10Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 139865-MAX3491ESD+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Communications & Networking, Industrial
Ultra Librarian 3D Model Ultra Librarian MAX3491ESD+ CAD Model

Description

MAX3491ESD+ RS-485/RS-422 Transceiver

The MAX3491ESD+ is a high-performance, low-power transceiver for RS-485 and RS-422 communication from Maxim Integrated. It features a half-duplex communication interface that is designed to meet the stringent requirements of the EIA/TIA-485 standard. This transceiver is suitable for long transmission lines in noisy environments due to its differential signaling, which provides robust data communication over distances up to 1200 meters.

The device operates from a single 3.3V supply, making it ideal for applications where power efficiency is critical. The MAX3491ESD+ is capable of data rates up to 10Mbps, allowing for high-speed data transmission in industrial control systems, networked devices, and telecommunications infrastructure.

With its fail-safe feature, the receiver output remains in a high state if the inputs are left open, shorted, or idle, ensuring signal integrity and reducing the risk of data loss. The transceiver also includes a hot-swap capability that prevents glitches on the bus lines when the device is powered up or down, enhancing system reliability.

The MAX3491ESD+ comes in a compact 14-pin SOIC package, making it easy to integrate into various designs without taking up significant board space. Its extended temperature range of -40°C to +85°C ensures reliable operation in extreme environments, which is essential for industrial and outdoor applications.

Key features of the MAX3491ESD+ include:

  • Half-duplex RS-485 and RS-422 communication
  • Single 3.3V supply operation
  • Up to 10Mbps data rate
  • True fail-safe receiver
  • Hot-swap capability
  • Thermal shutdown and short-circuit protection
  • 14-pin SOIC package
  • Extended temperature range: -40°C to +85°C

Overall, the MAX3491ESD+ is an excellent choice for designers looking for a reliable and power-efficient transceiver for RS-485/RS-422 applications. Its robust feature set ensures stable and secure data communication in a variety of challenging environments.
