Microchip Technology MCP4441-502E/ST Digital Potentiometer

The MCP4441-502E/ST is a digitally controlled potentiometer designed and manufactured by Microchip Technology. This device offers a versatile solution for applications requiring precise resistance adjustments. The MCP4441-502E/ST is part of Microchip's extensive digital potentiometer portfolio, known for their reliability and performance.

This particular model comes in a compact TSSOP-14 package, making it suitable for space-constrained applications. It features a quad-channel configuration, providing multiple channels of adjustable resistance in a single chip, which can be beneficial for design simplification and reducing board space.

The MCP4441-502E/ST operates with a resistance value of 5kΩ per potentiometer channel. It provides an I2C compatible interface, allowing for easy integration into a wide range of microcontroller-based systems. The I2C interface also enables daisy-chaining of multiple devices on the same bus, thereby expanding design flexibility without the need for additional microcontroller pins.

With a voltage range of 2.7V to 5.5V, the MCP4441-502E/ST can be used in various low-power and standard applications. It is characterized for operation from -40°C to +125°C, ensuring reliable performance across a broad spectrum of environmental conditions.

One of the key features of the MCP4441-502E/ST is its non-volatile memory (EEPROM), which allows the device to recall the last resistance setting upon power-up. This feature is particularly useful in applications where the potentiometer setting must be maintained between power cycles, such as in calibration or user preference settings in consumer electronics.

Applications for the MCP4441-502E/ST are diverse and include audio processing, industrial automation, automotive systems, and medical equipment. Its precision and programmability make it an ideal choice for adjusting voltage, tuning filters, controlling screen brightness, or calibrating sensors where fine resistance control is necessary.

Overall, the MCP4441-502E/ST is a highly versatile and reliable component that provides designers with an efficient solution for digital resistance adjustment, backed by Microchip Technology's reputation for quality and support.
