Microchip Technology USB2534-1080AEN-TR USB 2.0 Hub Controller

The USB2534-1080AEN-TR is a versatile and high-performance USB 2.0 hub controller from the esteemed Microchip Technology. This integrated circuit is designed to provide an efficient solution for expanding USB capabilities to various electronic devices. It is particularly well-suited for applications where multiple USB ports are required, such as desktop and laptop computers, docking stations, monitors, and embedded systems.

The USB2534-1080AEN-TR hub controller is part of Microchip's MultiTRAK™ series, which is known for its ability to support simultaneous USB 2.0 operations across multiple ports. This ensures a seamless and efficient data transfer experience for the end-user. The device is equipped with four downstream ports, enabling the connection of multiple peripherals with ease.

One of the key features of the USB2534-1080AEN-TR is its support for the USB 2.0 High-Speed (HS) interface, capable of data transfer rates up to 480 Mbps. It is also backward compatible with Full-Speed (FS) and Low-Speed (LS) devices, ensuring a broad range of compatibility with existing USB peripherals.

The controller is designed to be highly configurable, allowing designers to tailor its functionality to specific product requirements. It includes configurable vendor ID, product ID, device ID, and other parameters that can be programmed via an external EEPROM or via the SMBus. This level of customization ensures that the end product can be differentiated in the market.

For power management, the USB2534-1080AEN-TR includes features such as individual port power switching and over-current protection, providing a reliable user experience and safeguarding connected devices. The controller is also available in a space-saving 36-pin QFN package, making it an ideal choice for compact designs.

In summary, the Microchip USB2534-1080AEN-TR hub controller is a high-quality, feature-rich solution for expanding USB 2.0 functionality in a variety of electronic products. Its speed, reliability, and configurability make it a top choice for manufacturers looking to enhance their offerings with multiple USB connections.
