Same model may have multiple batches, images only for reference.
55959-1830 Real Image
Same model may have multiple batches, images only for reference.

55959-1830

Part No 55959-1830
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 18 POS 2mm Solder RA Thru-Hole Box/Tray
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color White
Contact Gender Male
Contact Material Brass
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 3 A
Flammability Rating UL94 V-0
Gender Male
Glow Wire Compliant Non-compliant
Housing Material Polyester
Insulation Resistance 1 GΩ
Lead Pitch 2 mm
Material Glass, Polyester
Max Current Rating 3 A
Maximum Operating Temperature 85 °C
Min Operating Temperature -25 °C
Mount Through Hole
Number of Circuits 18
Number of Contacts 18
Number of Poles 18
Number of Positions 18
Number of Rows 2
Orientation Right Angle
Pitch 2 mm
Plating Tin
REACH SVHC No SVHC
RoHS Compliant
Row Spacing 2.5 mm
Termination Solder
Voltage Rating 250 V
Voltage Rating (AC) 250 V
Voltage Rating (DC) 250 V
Working Voltage 250 V
Win Source Part Number 999191-55959-1830
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 55959-1830 CAD Model

Description

The Molex 999191-55959-1830 is an 18-position, 2 mm pitch, right angle, male connector for circular applications manufactured by Molex.

  • Positions: 18
  • Pitch: 2 mm
  • Orientation: right angle
  • Voltage Rating: 250 V
  • Current Rating: 3 A
  • Housing Material: polyester
  • Contact Material: brass
  • Contact Resistance: 20 mΩ
  • Mounting Type: through-hole
  • Maximum Operating Temperature: 85°C
