BC847B,215 Nexperia USA Inc. BC847B,215 real image15184
Same model may have multiple batches, images only for reference.
BC847B,215 Nexperia USA Inc. BC847B,215 real image15184
BC847B,215 Nexperia USA Inc. BC847B,215 real image15184
Same model may have multiple batches, images only for reference.

BC847B,215

Part No BC847B,215
Manufacturer Nexperia USA Inc.
Catalog TRANSISTORS
Description Bipolar Transistors - BJT 45 V, 100 mA NPN general-purpose transistors
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Nexperia
Mounting Style SMD/SMT
Package / Case SOT-23-3
Transistor Polarity NPN
Configuration Single
Collector- Emitter Voltage VCEO Max 45 V
Collector- Base Voltage VCBO 50 V
Emitter- Base Voltage VEBO 6 V
Collector-Emitter Saturation Voltage 200 mV
Maximum DC Collector Current 100 mA
Pd - Power Dissipation 250 mW
Gain Bandwidth Product fT 100 MHz
Minimum Operating Temperature - 65 C
Maximum Operating Temperature + 150 C
Packaging Cut Tape
Packaging MouseReel
Packaging Reel
DC Current Gain hFE Max 200 at 2 mA, 5 V
Height 1 mm
Length 3 mm
Technology Si
Width 1.4 mm
Brand Nexperia
DC Collector/Base Gain hfe Min 200 at 2 mA, 5 V
Product Type BJTs - Bipolar Transistors
Standard Pack Qty 3000
Subcategory Transistors
Ultra Librarian 3D Model Ultra Librarian BC847B,215 CAD Model

Description

Nexperia USA Inc.'s BC847B,215 is an NPN transistor with SMD (SMT) mounting.

  • Frequency-Transition: 100MHz
  • Maximum Collector-Emitter Breakdown Voltage: 45V
  • Maximum Power Dissipation: 250mW
  • Supply and Demand Status: Balance
  • Temperature Range: 150°C (TJ)
  • Package: TO-236AB (SOT23)
  • Typical Gain (hFE) (Min): 200 @ 2mA, 5V
