NRF51824-QFAA-R Real Image1 NRF51824-QFAA-R Real Image2
Same model may have multiple batches, images only for reference.
NRF51824-QFAA-R Real Image1 NRF51824-QFAA-R Real Image2
NRF51824-QFAA-R Real Image1 NRF51824-QFAA-R Real Image2
Same model may have multiple batches, images only for reference.

NRF51824-QFAA-R

Part No NRF51824-QFAA-R
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description AUTOMOTIVE BLUETOOTH LOW ENERGY / IC RF TxRx Only Bluetooth Bluetooth v4.0 2.4GHz 48-VFQFN Exposed Pad
Datasheet
NRF51824-QFAA-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless>RF Transceiver ICs
Mfr Nordic Semiconductors
Series nRF51
Package Tape & Reel (TR)
Type TxRx Only
RF Family/Standard Bluetooth
Protocol Bluetooth v4.0
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 2Mbps
Power - Output 4dBm
Sensitivity -96dBm
Memory Size 256kB Flash, 16kB RAM
Serial Interfaces I²C, SPI, UART, USB
GPIO 31
Voltage - Supply 1.9V ~ 3.6V
Current - Receiving 8.7mA ~ 13.4mA
Current - Transmitting 4.7mA ~ 16mA
Temperature Range - Operating -40°C ~ 105°C
Mounting Type Surface Mount
Package / Case 48-VFQFN Exposed Pad
Supplier Device Package 48-QFN (6x6)
Base Product Number NRF51824
REACH Status REACH Unaffected
Standard Package 3,000 pcs
Win Source Part Number 1383063-NRF51824-QFAA-R
Ultra Librarian 3D Model Ultra Librarian NRF51824-QFAA-R CAD Model

Description

The NRF51824-QFAA-R is an RF transceiver IC from Nordic Semiconductors.

  • Series: nRF51
  • Frequency: 2.4GHz
  • Protocol: Bluetooth v4.0
  • Memory Size: 256kB Flash, 16kB RAM
  • Power Output: 4dBm
  • Sensitivity: -96dBm
  • Data Rate: Up to 2Mbps
  • Serial Interfaces: I²C, SPI, UART, USB
  • Voltage Supply Range: 1.9V to 3.6V
  • Package: 48-VFQFN Exposed Pad
  • Mounting Type: Surface Mount
  • Moisture Sensitivity Level (MSL): 3 (168 Hours)
