The 74HCT93D, manufactured by NXP Semiconductors, is a high-speed Si-gate CMOS device and is pin-compatible with low-power Schottky TTL (LSTTL). It is designed to operate in the 2 V to 6 V range, which makes it suitable for a wide array of applications in both industrial and commercial markets.

Key Features

• Logic Family: The device belongs to the 74HCT family, which is known for its high noise immunity and low power consumption.
• 4-bit Binary Counter: It is a 4-bit binary ripple counter featuring a fully synchronous 4-stage counter that can provide a divide-by-16 function when connected in a specific configuration.
• Multiple Counting Modes: The 74HCT93D can be configured in various modes, including binary, BCD, and other counter configurations, making it versatile for different counting applications.
• Output Capability: The device offers standard outputs with a drive capability suitable for driving TTL loads over the entire VCC range.
• Temperature Range: It operates over a broad temperature range, typically from -40°C to +125°C, ensuring reliability in diverse operating conditions.
• Package: The 74HCT93D comes in a 14-pin SO package, which is widely used and recognized in the industry for its compact footprint and ease of PCB design.

Applications

The 74HCT93D is ideal for applications that require counting or timing functionalities. It can be used in:

• Industrial control systems
• Consumer electronics
• Automotive systems
• Personal computers
• Networking equipment

Quality and Reliability

NXP Semiconductors is committed to delivering products that meet the highest standards of quality and reliability. The 74HCT93D is subjected to rigorous testing and validation processes to ensure it meets these standards, making it a reliable choice for designers and engineers looking for a dependable counting solution.
