The 74LVC1G80GW is a high-performance, single positive-edge triggered D-type flip-flop with a wide range of applications in modern digital electronics. Manufactured by NXP Semiconductors, a leader in the industry, this component is part of the 74LVC family, which is renowned for its low-voltage operation and high-speed interface technology.

Key Features

• Low Voltage Operation: The device operates at a supply voltage range of 1.65V to 5.5V, making it suitable for battery-operated and low-power applications.
• High-Speed Performance: With a typical propagation delay of only a few nanoseconds, it is ideal for high-speed data processing and communication systems.
• 5V Tolerant Inputs: Inputs can tolerate 5V even when the device is powered at a lower voltage, providing interface flexibility with legacy systems.
• Output Drive Capability: Capable of driving up to 50mA, allowing for direct drive of LEDs or other low-power indicators.
• Low Power Dissipation: Ultra-low dynamic power consumption coupled with a very low static current makes it an energy-efficient choice.
• Multiple Package Options: Available in a variety of packages, including the very small and leadless 6-pin SOT363 package, which is ideal for space-constrained applications.

Applications

The 74LVC1G80GW is versatile and can be used in a broad spectrum of applications such as:

• Computing systems
• Telecommunications
• Data storage devices
• Portable electronics
• Industrial controls
• Medical equipment

Quality and Reliability

NXP Semiconductors is committed to delivering high-quality products. The 74LVC1G80GW is produced under stringent quality control measures, ensuring reliability and performance consistency. It is also supported by NXP's technical documentation and application support, making integration into your design a seamless process.

Environmental Compliance

The 74LVC1G80GW is compliant with the RoHS directive, which restricts the use of certain hazardous substances in electronic equipment, making it an environmentally responsible choice for your electronic designs.
