Product Overview: 74LVC2G17GM from NXP

The 74LVC2G17GM is a high-performance, dual Schmitt-trigger buffer produced by the renowned semiconductor manufacturer, NXP Semiconductors. This component is designed to provide a robust interface between two logic domains or to act as a line driver with its Schmitt-trigger inputs, which enhance noise immunity and transform slowly changing input signals into sharply defined jitter-free output signals.

Key Features

• Logic Type: The 74LVC2G17GM is a dual non-inverting buffer with Schmitt-trigger inputs, making it ideal for squaring up slow input rise and fall times.
• Supply Voltage Range: It operates on a very wide supply voltage range from 1.65V to 5.5V, allowing for use in various logic-level environments and compatibility with low-voltage devices.
• High-Speed Performance: The device boasts a propagation delay of only 3.7ns at a 3.3V supply, ensuring fast signal processing suitable for high-speed applications.
• Low Power Consumption: It features a low power consumption characteristic, with a typical quiescent current of only 1μA, which is essential for power-sensitive designs.
• ESD Protection: Enhanced electrostatic discharge (ESD) protection is built-in, with input protection tested to exceed JESD 22, ensuring the device's resilience to ESD events.
• Temperature Range: The device is operational over a broad temperature range from -40°C to +125°C, suitable for industrial applications.
• Packaging: This product is available in a very small XSON6 package, which is not only space-saving but also conducive to improved thermal performance and reduced parasitic inductance.

Applications

The 74LVC2G17GM is versatile and can be used in a variety of applications. It is particularly useful in signal conditioning, where input signals require cleaning before being fed into the next stage of a circuit. Additionally, it can be used in level shifting, where it helps in interfacing between different logic levels, and in line driving, where strong output drive is required to transmit signals over longer distances or through capacitive loads.

Quality and Reliability

NXP Semiconductors is known for its commitment to quality, and the 74LVC2G17GM is no exception. It is manufactured to the highest standards, ensuring both reliability and performance for critical applications in the commercial, industrial, and high-reliability markets.
