Product Overview: BZX585-C18/DG by NXP Semiconductors

The BZX585-C18/DG is a high-precision, low-power voltage regulator diode designed and manufactured by NXP Semiconductors. This product is part of NXP's extensive range of Zener diodes, which are known for their reliability and efficiency in voltage regulation applications. The BZX585-C18/DG is specifically engineered to provide a stable reference voltage of 18V, making it an ideal choice for precision voltage clamping and reference in a variety of electronic circuits.

This Zener diode comes in a small, leadless ultra-small Discrete Flat No-Lead (DFN) package, which is not only space-saving but also enhances thermal performance due to its low thermal resistance. The compact design of the BZX585-C18/DG allows for high-density mounting and is well-suited for modern miniaturized electronic devices.

Key Features:

• Regulation Voltage: Precisely regulated 18V output for consistent performance.
• Package Type: Ultra-small DFN package for space-saving and enhanced thermal conduction.
• Power Dissipation: Capable of dissipating up to 310 mW, ensuring stable operation under varying conditions.
• Low Leakage Current: Minimized leakage current for improved energy efficiency and reduced power loss.
• High Stability: Excellent stability over time and with temperature variations, providing reliable operation.
• RoHS Compliant: Meets the requirements of the Restriction of Hazardous Substances Directive, making it environmentally friendly.

Applications:

The BZX585-C18/DG is versatile and can be used in a wide range of applications. Its precision voltage regulation makes it suitable for use in:

• Power supply circuits
• Consumer electronics
• Telecommunication devices
• Computer peripherals
• Medical equipment
• Automotive electronics

With its robust design and reliable performance, the BZX585-C18/DG from NXP Semiconductors is an excellent choice for designers looking for a high-quality voltage reference solution.
