NXP PCA9516AD I²C-Bus Repeater

The NXP PCA9516AD is a sophisticated integrated circuit designed to facilitate robust I²C-bus communication in complex environments. This I²C-bus repeater allows for the extension of the I²C-bus by buffering both the data (SDA) and the clock (SCL) lines, enabling the connection of multiple devices over extended distances.

Key Features

• 5-Channel Hub: The PCA9516AD integrates five bidirectional channels that can be used to create a branching I²C-bus network.
• Voltage Level Translation: It operates over a wide supply voltage range (2.3V to 5.5V) and can translate between different voltage levels, making it suitable for multi-voltage systems.
• High Noise Immunity: With built-in hot-swap capabilities, it ensures a high level of noise immunity and prevents glitches on the I²C-bus during live insertion and removal of boards.
• Low Standby Current: The device's low standby current is a boon for power-sensitive applications.

Applications

The PCA9516AD is ideal for a variety of applications where I²C-bus signal integrity is crucial. It is commonly used in:

• Server and telecom infrastructure
• Industrial control systems
• Consumer electronics
• Automotive networks

Package and Quality

Encased in a compact 16-pin TSSOP package, the PCA9516AD is designed for space-constrained applications. It is compliant with the stringent quality standards required for industrial and automotive applications, ensuring reliable performance in diverse operating conditions.

Ordering Information

The NXP PCA9516AD is available for order under the part number PCA9516AD,112. For detailed specifications, technical documentation, and ordering information, customers are encouraged to visit the official NXP Semiconductors website or contact authorized distributors.
