The NXP PCT2075GVX is a temperature-to-digital converter featuring ±1°C accuracy over -25°C to +100°C and ±2°C accuracy over -55°C to +125°C. This high-precision sensor is an ideal solution for a wide range of applications, including system thermal management, personal electronics, industrial controls, and any other system that requires accurate temperature monitoring.

Key Features

• I²C-bus interface: The PCT2075GVX supports a standard I²C-bus interface, facilitating easy integration into most microcontroller-based systems.
• Programmable temperature threshold: Users can set a temperature threshold, which, when exceeded, will trigger an interrupt that alerts the system to take appropriate action.
• Programmable temperature hysteresis: This feature allows users to set a differential temperature range to prevent frequent triggering of the temperature threshold interrupt.
• Low power consumption: Designed for energy efficiency, this sensor is suitable for battery-powered devices, thanks to its low standby current.
• Supply voltage range of 2.7V to 5.5V: The PCT2075GVX operates over a wide supply voltage range, making it versatile for various applications.

Advanced Specifications

The device boasts a high resolution of 0.125°C and features a shutdown mode to conserve power. The operating temperature range of -55°C to +125°C ensures that the sensor can perform reliably in extreme conditions.

Package Information

The PCT2075GVX comes in a very small XSON8 package, which is excellent for space-constrained applications. Its small footprint does not compromise its performance or reliability.

Application Areas

With its robust feature set, the PCT2075GVX is well-suited for a variety of applications, including:

• Computer servers and networking equipment
• Office electronics
• Medical and healthcare systems
• Industrial and automotive systems
• Smart home devices and IoT applications

For engineers and designers looking for a reliable and precise temperature sensor, the NXP PCT2075GVX offers an excellent balance of performance, power efficiency, and versatility, making it a top choice for integrating temperature sensing capabilities into their projects.
