The FPA600-150R-J is a high-power thick film resistor manufactured by Ohmite. Part of the FPA600 series, this resistor is designed for demanding applications requiring high power dissipation, excellent pulse handling capabilities, and reliable performance in harsh environments. The 150R designation indicates a resistance value of 150 ohms.

Applications

• Power supplies
• Motor control circuits
• Snubber circuits
• Inrush current limiting
• Braking resistors
• High-frequency applications

Features

• High Power Rating: Designed to dissipate significant power (600W) without compromising performance or reliability.
• Thick Film Construction: Provides excellent stability, reliability, and pulse handling capability.
• Non-Inductive Design: Minimizes inductance, making it suitable for high-frequency applications.
• Direct Mounting: Designed for direct mounting to a heat sink for optimal thermal management.
• RoHS Compliant: Meets Restriction of Hazardous Substances (RoHS) environmental standards.
• Compact Size: Offers a high power-to-volume ratio.

Benefits

• Reliable Performance: The thick film construction ensures long-term stability and reliable operation in demanding environments.
• Efficient Heat Dissipation: Direct mounting to a heat sink enables efficient heat dissipation, maximizing power handling capability.
• Versatile Applications: Suitable for a wide range of power applications due to its high power rating, non-inductive design, and pulse handling capabilities.
• Compact Design: The compact size allows for integration into space-constrained designs.
• Environmentally Friendly: RoHS compliance ensures adherence to environmental regulations, minimizing the use of hazardous substances.
• Reduced Inductance: The non-inductive design makes it suitable for use in high-frequency applications where inductance can be detrimental.

Additional Details

The FPA600-150R-J has a resistance tolerance that is typically 5%. It is crucial to mount the resistor on an appropriate heat sink to achieve its rated power dissipation. Proper heat sink selection depends on the ambient temperature and the amount of power being dissipated. Detailed derating curves are often available in the product datasheet. The resistor is designed for operation within a specified temperature range. This resistor is often bolted directly to a chassis or other metal surface for heat sinking.
