ON Semiconductor MBRAF440T3G Schottky Barrier Rectifier

The MBRAF440T3G is a high-performance Schottky Barrier Rectifier designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This rectifier is engineered to offer efficient and fast switching capabilities with a low forward voltage drop. It is widely used in various applications, including power supply, converters, free-wheeling diodes, and reverse battery protection.

Key Features

• High Surge Capacity: The device can handle a high level of surge current, making it suitable for applications that experience occasional surge events.
• Low Power Loss: With its low forward voltage drop, the MBRAF440T3G ensures minimal power loss during operation, which enhances the overall efficiency of the system it is used in.
• High Current Capability: The device is capable of conducting a high amount of current, making it ideal for high-power applications.
• Temperature Resilience: It operates effectively over a wide temperature range, ensuring reliability under varying environmental conditions.

Specifications

Parameter Value Package SMB (DO-214AA) Peak Repetitive Reverse Voltage (V<sub>RRM) 40V Average Rectified Forward Current (I<sub>o) 4A Forward Voltage Drop (V<sub>F) 0.38V @ 4A Operating Temperature Range -55°C to +150°C RoHS Compliant Yes

Applications

The MBRAF440T3G's robust design and efficient performance make it an ideal choice for a broad range of applications. It is commonly used in DC/DC converters, automotive systems, power management devices, and other power-sensitive electronics where efficiency and reliability are of utmost importance.

Environmental Compliance

In line with ON Semiconductor's commitment to environmental sustainability, the MBRAF440T3G is RoHS compliant, which means it is free from harmful substances such as lead, mercury, and cadmium. This compliance ensures that the product is suitable for use in environmentally sensitive applications and contributes to the reduction of electronic waste and its negative impact on the environment.
