The MC34060ADR2G is a versatile and robust Pulse Width Modulation (PWM) controller integrated circuit (IC) designed and manufactured by ON Semiconductor. This IC is engineered to offer precise voltage regulation, efficient power management, and is widely used in a variety of power conversion and control applications.

The device operates at a fixed frequency which can be programmed by the user with external components. Its wide operable frequency range makes it suitable for several applications including switch-mode power supplies, DC-DC converters, motor control circuits, and various other power control designs.

Key Features

• Versatility: The MC34060ADR2G is designed to cater to a broad spectrum of power management requirements, making it a go-to solution for designers looking for a general-purpose PWM controller.
• Adjustable Output: Users can set the desired output control by adjusting the duty cycle through external components, offering flexibility in the design of the power supply circuit.
• Frequency Range: The frequency of operation is adjustable from a few hundred hertz to several hundred kilohertz, allowing for customization to the power supply's requirements.
• Protection Features: It includes built-in features such as under-voltage lockout, cycle-by-cycle current limiting, and thermal shutdown protection, ensuring safe operation under various conditions.
• Package: The MC34060ADR2G comes in an 8-SOIC (0.154", 3.90mm Width) package, which is compact and suitable for space-constrained applications.

Applications

• Switch-Mode Power Supplies (SMPS)
• DC-to-DC Converters
• Motor Control Circuits
• Power Inverters

ON Semiconductor's MC34060ADR2G is a reliable and flexible solution for engineers and designers looking to implement PWM control in their power management systems. Its combination of protection features, adjustable parameters, and wide frequency range makes it a valuable component for a multitude of electronic products and applications.
