Category Isolators - Special Purpose Isolators
Mfr ON Semiconductor
Package Tube
Product Status Obsolete
Type AC Line Monitor
Number of Channels 1
Voltage - Isolation 2500Vrms
Input Type AC, DC
Current - Output / Channel 20mA
Propagation Delay tpLH / tpHL (Max) 1ms, 1ms (Typ)
Voltage - Forward (Vf) (Typ) 1.5 V
Current - DC Forward (If) (Max) 30 mA
Voltage - Supply 7V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Package / Case 8-DIP (0.300", 7.62mm)
Supplier Device Package 8-DIP
Approval Agency UR
Base Product Number MID40
Standard Package 50 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 231174-MID400
Ultra Librarian 3D Model Ultra Librarian MID400 CAD Model

Description

ON Semiconductor MID400 Line Monitor

The ON Semiconductor MID400 is a robust line monitor chip designed for applications that require accurate detection of AC and DC line voltage statuses. This versatile component is essential for systems that demand reliable monitoring of power lines to ensure safety, efficiency, and proper operation. The MID400 offers a unique blend of simplicity and effectiveness, making it an ideal choice for a wide range of industrial, commercial, and consumer products.

Key Features

  • High Voltage Sensing: The MID400 is capable of monitoring line voltages, providing designers with a flexible solution for various voltage levels.
  • Optoisolation: With built-in optoisolation, the MID400 ensures that the monitoring circuitry is electrically isolated from the high voltage line, enhancing safety and system reliability.
  • AC and DC Detection: This device can detect both AC and DC line voltages, offering a comprehensive monitoring solution.
  • Fast Response Time: The MID400 has a rapid response time, which is critical for systems that require immediate action upon detection of line voltage changes.
  • Minimal External Components: The need for additional components is minimized, making the MID400 a cost-effective and space-saving option for line monitoring applications.

Applications

  • Power supply monitoring
  • Motor control systems
  • Industrial automation
  • Overvoltage and undervoltage protection
  • Battery chargers
  • Energy management systems

The MID400 from ON Semiconductor is a reliable and efficient solution for monitoring line voltages in various electronic systems. Its ability to provide quick and accurate voltage status feedback makes it an indispensable component in applications where power line conditions are critical. With its high degree of electrical isolation and minimal need for external components, the MID400 simplifies design and enhances the overall safety and performance of electronic systems.

Whether you're designing a power supply, managing an industrial automation project, or developing a sophisticated energy management system, the MID400 offers the performance and reliability needed to keep your systems running smoothly and safely.
