Product Overview: NCP4687DH12T1G

The NCP4687DH12T1G is a high-performance, low-dropout voltage regulator designed and manufactured by ON Semiconductor, a leading provider of semiconductor-based solutions. This component is engineered to deliver a fixed output voltage of 1.2V with an input voltage range from 2.5V to 5.5V, making it particularly suitable for battery-powered devices and low-voltage applications.

Key Features

• Output Voltage: Precisely regulated 1.2V output, ideal for consistent power supply needs.
• High Accuracy: Maintains output voltage accuracy within ±1%, ensuring reliable performance for sensitive electronics.
• Low Dropout: The low dropout voltage minimizes power loss and improves efficiency, especially critical when operating with low input voltages.
• Current Capability: Capable of supplying up to 150 mA of output current, suitable for a variety of low-power applications.
• Thermal Shutdown: Integrated thermal shutdown feature protects the device from overheating, enhancing its reliability and longevity.
• Current Limit: Built-in current limit prevents damage to the regulator during fault conditions such as output short circuits.
• Package: Available in a compact, surface-mountable 5-Pin TSOP-5 package, which is space-efficient for modern PCB designs.

Applications

The NCP4687DH12T1G is versatile and can be used in a wide array of electronic devices. It is particularly suited for applications such as:

• Portable and battery-powered devices
• Microcontroller power supplies
• Mobile phones and personal media players
• Wireless communication systems
• Peripheral power supplies

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The NCP4687DH12T1G is produced with rigorous quality controls and is designed to meet the demanding standards of the electronics industry. With its robust design and ON Semiconductor's reputation for reliability, this voltage regulator is an excellent choice for designers looking for a dependable power management solution.
