ON Semiconductor NCP715MX33TBG Voltage Regulator

The NCP715MX33TBG from ON Semiconductor is a high-performance, low-dropout voltage regulator designed to deliver a fixed output voltage of 3.3V with an output current of up to 50 mA. This compact and efficient component is an ideal choice for portable and battery-powered applications where power efficiency is crucial.

With an ultra-low quiescent current of just 4 µA, the NCP715MX33TBG helps to extend the battery life of portable devices by minimizing the power consumed when in standby mode. The device operates over a wide input voltage range from 2.5V to 24V, providing versatility and reliability in various applications, including but not limited to consumer electronics, IoT devices, and microcontroller power supplies.

The NCP715MX33TBG features a built-in thermal shutdown and current limit protection, enhancing the safety and durability of the end product by preventing damage due to overheating and overcurrent conditions. These protection features make the voltage regulator a robust choice for sophisticated electronic systems.

The regulator's small footprint is encapsulated in a 5-pin TSOP-5 package, making it suitable for space-constrained applications. Its surface-mount design allows for efficient assembly in automated manufacturing processes, thus reducing production costs and time.

Key specifications include:

• Fixed Output Voltage: 3.3V
• Output Current: Up to 50 mA
• Input Voltage Range: 2.5V to 24V
• Quiescent Current: 4 µA (Typical)
• Dropout Voltage: 250 mV at 50 mA Load
• Package: TSOP-5
• Operating Temperature Range: -40°C to +85°C
• Protections: Thermal Shutdown and Current Limit

With its high-performance features and compact design, the NCP715MX33TBG is an excellent choice for engineers and designers looking to optimize power management in their next project while maintaining a small form factor. ON Semiconductor's commitment to quality ensures that this voltage regulator will provide reliable performance in a wide array of devices and applications.
