ON Semiconductor NTJD1155LT1G - Product Overview

The NTJD1155LT1G is a high-performance, dual N- and P-Channel Power MOSFET from ON Semiconductor, a leading provider of semiconductor-based solutions. This product is designed to deliver efficient power management and switching with a compact footprint, making it ideal for a wide range of applications.

Key Features

• Device Type: Power MOSFET, Dual N- and P-Channel
• Package: Ultra-small leadless package (2x2mm UDFN)
• Drain-to-Source Voltage (V<sub>DS): N-Channel: 20V, P-Channel: -20V
• Continuous Drain Current (I<sub>D): N-Channel: 3A, P-Channel: -2.4A
• Power Dissipation (P<sub>D): 1.25W
• R<sub>DS(on): Low on-resistance for efficient operation
• Gate Charge (Q<sub>g): Optimized for low gate charge
• Compliance: RoHS compliant

Applications

The NTJD1155LT1G is versatile and can be used in a variety of applications, including:

• Power management for portable and battery-powered devices
• DC/DC converters
• Load/switching circuits
• Motor control applications

Performance and Quality

ON Semiconductor's NTJD1155LT1G is engineered for performance and reliability. The device's low on-resistance ensures minimal voltage drop and power loss, providing a more efficient circuit operation. Additionally, the optimized gate charge reduces switching losses, which is critical for high-frequency applications.

Environmental Compliance

Environmental sustainability is a priority for ON Semiconductor. The NTJD1155LT1G is RoHS compliant, meaning it is free from hazardous substances commonly used in electronics. This compliance ensures that the product is not only safe for consumers but also minimizes the environmental impact throughout its lifecycle.

Conclusion

The NTJD1155LT1G from ON Semiconductor offers a powerful solution for designers seeking a dual N- and P-Channel Power MOSFET with a compact form factor. Its low on-resistance, high current capability, and efficiency make it a top choice for a range of power management applications. With ON Semiconductor's commitment to quality and environmental standards, the NTJD1155LT1G stands out as a reliable and eco-friendly component for modern electronic designs.
