The NTS4101PT1G by ON Semiconductor is a high-performance P-Channel MOSFET designed for power management applications. This small-signal field-effect transistor is an essential component for designers looking to improve efficiency and reduce power consumption in a variety of electronic devices.

Key Features

• Voltage Rating: The NTS4101PT1G operates at a drain-source voltage of -20V, making it suitable for a range of low-voltage applications.
• Current Capacity: With a continuous drain current of -4.9A, this MOSFET can handle significant power for its size.
• RDS(on): It boasts a low on-resistance of just 54 mOhms at VGS = -4.5V, ensuring high efficiency and minimal power loss during operation.
• Package: Housed in a space-saving SOT-23 package, the NTS4101PT1G is ideal for compact circuit designs.
• Gate Charge: A low gate charge enables fast switching speeds, which is critical for reducing switching losses in power conversion circuits.

Applications

The NTS4101PT1G is versatile and can be used in various applications, including:

• Power Management Circuits
• Load Switches
• Battery Management Systems
• DC-DC Converters
• Portable Devices

Reliability and Performance

ON Semiconductor is known for its commitment to quality and reliability, and the NTS4101PT1G is no exception. It is designed to meet stringent industry standards, ensuring long-term reliability and consistent performance in demanding environments.

Environmental Compliance

The NTS4101PT1G is compliant with RoHS regulations, which means it is manufactured without the use of hazardous substances. This compliance reflects ON Semiconductor's dedication to environmental responsibility and the production of eco-friendly products.

Ordering Information

For ordering, the product is available with the designation NTS4101PT1G and is supplied in tape and reel packaging for efficient assembly during the manufacturing process. For detailed information on pricing and availability, please contact ON Semiconductor or an authorized distributor.
