The 2SD1707 is a silicon NPN epitaxial planar transistor manufactured by Panasonic. This transistor is designed for switching applications, particularly in power supplies, DC-DC converters, and motor drivers. Its key features include a high collector current and low saturation voltage.

Applications:

• Power Supplies
• DC-DC Converters
• Motor Drivers
• Switching Regulators
• Relay Drivers

Features:

• NPN Silicon Epitaxial Planar Transistor
• High Collector Current (IC)
• Low Saturation Voltage (VCE(sat))
• High Breakdown Voltage
• Fast Switching Speed

Benefits:

• Provides efficient and reliable switching performance in power supplies.
• Enables efficient DC-DC conversion.
• Allows precise control of motors.
• Minimizes power loss during switching operations.
• Ensures stable operation in high-voltage applications.

Technical Specifications:

Collector-Base Voltage (VCBO): 60V
Collector-Emitter Voltage (VCEO): 50V
Emitter-Base Voltage (VEBO): 6V
Collector Current (IC): 5A
Collector Dissipation (PC): 20W
Transition Frequency (fT): 50 MHz (Typical)
Operating Temperature Range: -55°C to +150°C

The 2SD1707 is typically packaged in a TO-252 or similar surface-mount package, making it suitable for automated assembly. As always, refer to the official Panasonic datasheet for the most accurate and detailed specifications, application notes, and thermal considerations. Proper heat sinking is often necessary to ensure reliable operation at higher power levels. The transistor's robust characteristics and efficient switching capabilities make it a good choice for various power electronics applications.
