ALE15B12 Real Image
Same model may have multiple batches, images only for reference.

ALE15B12

Part No ALE15B12
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE SPST 16A 12V
Datasheet
ALE15B12 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Obsolete(EOL)
Relay Type General Purpose
Coil Type Non Latching
Coil Current 33.3mA
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 16A
Switching Voltage 277VAC - Max
Turn On Voltage (Max) 9 VDC
Turn Off Voltage (Min) 0.6 VDC
Operate Time 20ms
Release Time 20ms
Features Insulation - Class B
Mounting Through Hole
Termination Style PC Pin
Coil Power 400 mW
Coil Resistance 360 Ohms
Temperature Range - Operating -40°C to 85°C
Win Source Part Number 48141-ALE15B12
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ALE15B12 CAD Model

Description

Product Overview

The ALE15B12 DC-DC converter offers superior performance in voltage conversion, providing stability and efficiency in demanding environments. This component is ideal for a range of high-tech applications.

Features and Benefits

  • Stable output for consistent performance
  • Broad temperature operating range
  • Protection features for reliability

Applications

  • Automotive electronics
  • Data communication systems
  • Medical equipment

Designed with adaptability and durability in mind, the ALE15B12 is essential for engineers focusing on sophisticated electronic designs.
