The HP8S36 is an RF MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) manufactured by Rohm Semiconductor. It is specifically designed for high-frequency applications, providing excellent performance in RF amplifiers, mixers, and switches. This MOSFET offers low noise, high gain, and efficient power amplification, making it suitable for various wireless communication systems and radar applications.

Applications

• RF Amplifiers: Used in cellular base stations, wireless routers, and radio transmitters to amplify signals.
• Mixers: Employed in frequency converters to mix signals for up-conversion or down-conversion.
• Switches: Utilized in RF switches to route signals in different paths.
• Radar Systems: Integrated into radar transceivers for signal amplification and switching.
• Satellite Communication: Used in satellite receivers and transmitters for signal processing.

Features

• High Gain: Provides significant signal amplification for improved system performance.
• Low Noise: Minimizes noise figure for enhanced signal-to-noise ratio.
• High-Frequency Performance: Optimized for operation in the RF range.
• Low Input Capacitance: Reduces signal distortion and improves bandwidth.
• Small Package Size: Enables compact designs in densely populated circuits.

Benefits

• Improved Signal Quality: Enhances signal strength and reduces noise for clear communication.
• Efficient Power Amplification: Maximizes power output while minimizing power consumption.
• Reliable Performance: Ensures stable operation in demanding RF environments.
• Compact Design: Allows for miniaturization of RF circuits.
• Versatile Application: Suitable for a wide range of RF and microwave applications.

Specifications

The HP8S36 RF MOSFET features a drain-source voltage (VDS) of 6 V. It has a drain current (ID) of 30 mA. The gate-source voltage (VGS) is typically 3 V. The noise figure is typically 1.5 dB at 2 GHz. The gain is typically 15 dB at 2 GHz. The operating frequency range extends up to 6 GHz. The package type is SOT-343. The operating temperature range is -55°C to +150°C. The device meets RoHS compliance standards.
