RDN050N20 Rohm Semiconductor RDN050N20 Real Image RDN050N20 real image 2 RDN050N20 label picture 2 RDN050N20 real image
Same model may have multiple batches, images only for reference.
RDN050N20 Rohm Semiconductor RDN050N20 Real Image RDN050N20 real image 2 RDN050N20 label picture 2 RDN050N20 real image
RDN050N20 Rohm Semiconductor RDN050N20 Real Image RDN050N20 real image 2 RDN050N20 label picture 2 RDN050N20 real image
Same model may have multiple batches, images only for reference.

RDN050N20

Part No RDN050N20
Manufacturer Rohm Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 5A TO-220FN
Datasheet
RDN050N20 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Bulk
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 5A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 1mA
Max Gate Charge 18.6nC @ 10V
Max Input Capacitance 292pF @ 10V
Maximum Gate-Source Voltage ±30V
Power Dissipation (Max) 30W (Tc)
Maximum Rds On at Id,Vgs 720 mOhm @ 2.5A, 10V
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-220FN
Dimension TO-220-3 Full Pack
Win Source Part Number 042306-RDN050N20
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RDN050N20 CAD Model

Description

The RDN050N20 is a MOSFET transistor manufactured by Rohm Semiconductor.

  • Maximum Power Dissipation: 30W
  • Applications: Power amplifiers, inverters, and switching circuits
  • Channel Type: N-channel
  • Drain-Source Breakdown Voltage: 200V
  • Gate-Source Threshold Voltage: 4V @ 1mA
  • Maximum Gate-Source Voltage: ±30V
  • Maximum Rds On at Id, Vgs: 720 mOhm @ 2.5A, 10V
  • Packaging: Bulk
  • Mounting Type: Through-hole
  • Supply and Demand Status: Balanced
  • Operating Temperature Range: 150°C (TJ)
  • Dimension: TO-220-3 Full Pack
