RTR030N05TL Real Image RTR030N05TL real image5232 RTR030N05TL Real Image1 RTR030N05TL Real Image2
Same model may have multiple batches, images only for reference.
RTR030N05TL Real Image RTR030N05TL real image5232 RTR030N05TL Real Image1 RTR030N05TL Real Image2
RTR030N05TL Real Image RTR030N05TL real image5232 RTR030N05TL Real Image1 RTR030N05TL Real Image2
Same model may have multiple batches, images only for reference.

RTR030N05TL

Part No RTR030N05TL
Manufacturer Rohm Semiconductor
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 45V 3A TSMT3
Datasheet
RTR030N05TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 45V
Continuous Drain Current at 25°C 3A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Gate-Source Threshold Voltage 1.5V @ 1mA
Max Gate Charge 6.2nC @ 4.5V
Max Input Capacitance 510pF @ 10V
Maximum Gate-Source Voltage ±12V
Power Dissipation (Max) 1W (Ta)
Maximum Rds On at Id,Vgs 67 mOhm @ 3A, 4.5V
Temperature Range - Operating 150°C (TJ)
Mounting SMD (SMT)
Case / Package TSMT3
Dimension SC-96
Win Source Part Number 027644-RTR030N05TL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RTR030N05TL CAD Model

Description

The Rohm Semiconductor RTR030N05TL is a medium-popularity N-channel MOSFET that is designed for use in a variety of applications.

  • Maximum Power Dissipation: 1W (Ta)
  • Maximum Drain-Source Breakdown Voltage: 45V
  • Maximum Rds On @ Id,Vgs: 67 mOhm @ 3A, 4.5V
  • Maximum Gate-Source Voltage: ±12V
