Same model may have multiple batches, images only for reference.
FTSH-104-01-F-DV-P-TR Real Image
Same model may have multiple batches, images only for reference.

FTSH-104-01-F-DV-P-TR

Part No FTSH-104-01-F-DV-P-TR
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 8POS 1.27MM / Connector Header Surface Mount 8 position 0.050" (1.27mm)
Datasheet
FTSH-104-01-F-DV-P-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series FTSH
Package Tape & Reel
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 8
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.120" (3.05mm)
Insulation Height 0.099" (2.51mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 3.00µin (0.076µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Features Pick and Place
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3.4A per Contact
Base Product Number FTSH-104
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names SAM13921DKR,FTSH-104-01-F-DV-P-TR-ND,SAM13921CT,FTSH-104-01-F-DV-P-FR,SAM13921TR
Standard Package 475
Win Source Part Number 999643-FTSH-104-01-F-DV-P-TR
Ultra Librarian 3D Model Ultra Librarian FTSH-104-01-F-DV-P-TR CAD Model

Description

The FTSH-104-01-F-DV-P-TR is a rectangular connector header with male pins from the FTSH series.

  • Positions: 8
  • Pitch: 0.050" (1.27mm)
  • Applications: Board to board or cable
  • Shrouded: Unshrouded
  • Features: Cuttable header with pick and place features
  • Contact Type: Male pin
  • Loaded: All positions
  • Contact Material: Phosphor bronze
  • Contact Finish: Gold with a thickness of 3.00µin (0.076µm)
  • Termination: Solder
  • Fastening Type: Push-pull
  • Packaging: Tape & reel
  • Standard Package: 475
  • Manufacturer: Samtec Inc.
  • Compliance: REACH regulations
