2SA1294 Real Image 2SA1294 real image
Same model may have multiple batches, images only for reference.
2SA1294 Real Image 2SA1294 real image
2SA1294 Real Image 2SA1294 real image
Same model may have multiple batches, images only for reference.

2SA1294

Part No 2SA1294
Manufacturer Sanken
Catalog Transistors (BJT) - Single
Description TRANS PNP 230V 15A TO-3P
Datasheet
2SA1294 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Sanken
Packaging Bulk
Status Active
Transistor Polarity PNP
Maximum Current Collector 15A
VCEO Maximum Collector-Emitter Breakdown Voltage 230V
Max Vce (sat) 2V @ 500mA, 5A
Collector Cut-off Current(Max) 100μA (ICBO)
Typical Gain (hFE) (Min) 50 @ 5A, 4V
Maximum Power Dissipation 130W
Frequency - Transition 35MHz
Temperature Range - Operating 150°C (TJ)
Mounting Through Hole
Case / Package TO-3P
Win Source Part Number 1004154-2SA1294
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Audio, Industrial
Ultra Librarian 3D Model Ultra Librarian 2SA1294 CAD Model

Description

The Sanken 2SA1294 is a PNP transistor that has a maximum collector-emitter breakdown voltage of 230V and a maximum current collector of 15A.

  • Maximum Collector-Emitter Breakdown Voltage: 230V
  • Maximum Current Collector: 15A
  • Frequency Transition: 35MHz
  • Package: TO-3P
  • Application: Audio and Industrial
  • Supply and Demand Status: Balanced
  • Packaging: Bulk
  • Mounting: Through-Hole
