Same model may have multiple batches, images only for reference.
8501CO21V20 Schneider Electric – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

8501CO21V20

Part No 8501CO21V20
Manufacturer Schneider Electric
Catalog Power Relays, Over 2 Amps
Description POWER RELAY, TYPE C, 20A RESISTI
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Mounting Type Chassis Mount
Coil Voltage 120VAC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 20 A
Switching Voltage 500VDC - Max
Load - Max Switching 10000VA
Coil Type Non Latching
Termination Style Screw Terminal
Temperature Range - Operating -30°C ~ 50°C
Approval Agency CE, CSA, UL
Relay Type General Purpose
Package Box
Supply and Demand Status Shortage
Win Source Part Number 1548835-8501CO21V20
Ultra Librarian 3D Model Ultra Librarian 8501CO21V20 CAD Model
