DST-6-28 Real Image
Same model may have multiple batches, images only for reference.

DST-6-28

Part No DST-6-28
Manufacturer Signal Transformer
Catalog Power Transformers
Description PWR XFMR LAMINATED 20VA TH  /
Datasheet
DST-6-28 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers>Power Transformers
Mfr Signal Transformer
Series DST
Package Box
Type Laminated Core
Voltage - Primary 115V, 230V
Voltage - Secondary (Full Load) Parallel 14V, Series 28V
Current - Output (Max) Parallel 1.4A, Series 700mA
Primary Winding(s) Dual
Secondary Winding(s) Dual
Center Tap No
Power - Max 20VA
Mounting Type Through Hole
Termination Style PC Pin
Dimension 57.20mm L x 47.60mm W
Height - Seated (Max) 36.90mm
Voltage - Isolation 2500Vrms
Weight 0.8 lb (362.87 g)
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.31.4035
Other Names DST628,595-1221
Standard Package 25
Win Source Part Number 1141437-DST-6-28
Ultra Librarian 3D Model Ultra Librarian DST-6-28 CAD Model

Description

The DST6-28 from Signal Transformer is a laminated core power transformer with a maximum power rating of 20 VA.

  • Power Rating (Max): 20 VA
  • Windings: Dual Primary and Secondary
  • Connection: Parallel or Series
  • Voltage Isolation: 2500Vrms
  • Input Voltage: 115V or 230V
  • Output Current (Parallel): 1.4A
  • Output Current (Series): 700mA
  • Voltage Output (Parallel): 14V
  • Voltage Output (Series): 28V
  • Package Type: Box
  • Mounting Type: Through-Hole
  • Dimensions: 57.20mm L x 47.60mm W x 36.90mm H
  • Series: DST
  • Alternative: DST6-28
