CP2104-F03-GM Real Image CP2104-F03-GM real image23068 CP2104-F03-GM real image23069 CP2104-F03-GM Real Image
Same model may have multiple batches, images only for reference.
CP2104-F03-GM Real Image CP2104-F03-GM real image23068 CP2104-F03-GM real image23069 CP2104-F03-GM Real Image
CP2104-F03-GM Real Image CP2104-F03-GM real image23068 CP2104-F03-GM real image23069 CP2104-F03-GM Real Image
Same model may have multiple batches, images only for reference.

CP2104-F03-GM

Part No CP2104-F03-GM
Manufacturer Silicon Labs
Catalog Interface - Controllers
Description IC SGL USB-TO-UART BRIDGE 24QFN
Datasheet
CP2104-F03-GM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Silicon Labs
Packaging Tube
Protocol USB
Function Bridge, USB to UART
Interface UART
Standards USB 2.0
Supply Voltage (V) 1.8V, 3V ~ 3.6V
Current - Supply 17mA
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 24-WFQFN Exposed Pad
Supplier Device Package 24-QFN (4x4)
Part Number Series CP2104
Manufacturer Pack Quantity 91
MSL Level 1 (Unlimited)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 812781-CP2104-F03-GM
Ultra Librarian 3D Model Ultra Librarian CP2104-F03-GM CAD Model

Description

The Silicon Labs CP2104-F03-GM is a USB to UART bridge with USB protocol. The manufacturer is Silicon Labs.

  • Package: 24-QFN (4x4)
  • Current Supply: 17mA
  • USB Compliance: USB 2
  • Supply and Demand Status: Limited
  • Manufacturer Pack Quantity: 91
  • MSL Level: 1 (unlimited)
  • Supply Voltage Range: 1.8V, 3V to 3.6V
  • Part Number Series: CP2104
  • Operating Temperature Range: -40°C to 85°C
  • Manufacturer Package: 24-WFQFN Exposed Pad
