The SL2309SI-1HT is a low-cost clock synthesizer designed by Skyworks Solutions Inc. It is commonly used for generating clock signals in various electronic systems. The device features a phase-locked loop (PLL) that allows it to create precise output frequencies from a reference clock. The SL2309SI-1HT is known for its simplicity, reliability, and cost-effectiveness, making it a popular choice for applications where a stable clock source is required.

Applications

• PC motherboards
• Graphics cards
• Embedded systems
• Networking devices (routers, switches)
• Consumer electronics (set-top boxes, DVD players)
• Printers

Features

• Low-cost clock synthesizer
• Generates multiple output clocks
• Operating frequency up to 200 MHz
• Phase-locked loop (PLL) for frequency synthesis
• Input clock frequency range: 3.3 MHz to 50 MHz
• Output clock enable control
• 3.3V operating voltage
• Available in TSSOP package

Benefits

• Provides a stable and accurate clock source
• Reduces BOM cost compared to discrete clock components
• Simplified system design
• Improved system performance
• Easy to implement in various applications
• Small footprint

Additional Details

The SL2309SI-1HT utilizes a PLL to multiply or divide the input reference clock to generate the desired output frequencies. It supports multiple output clocks, allowing it to provide clock signals for different system components. The device features an output clock enable control, which allows the user to enable or disable the output clocks as needed. The SL2309SI-1HT operates at a 3.3V supply voltage and is available in a TSSOP (Thin Shrink Small Outline Package). This package provides a small footprint and is easy to solder onto a PCB. The device is commonly used in PC motherboards, graphics cards, embedded systems, and networking devices to provide stable and accurate clock signals for various system components. It is also suitable for consumer electronics applications such as set-top boxes and DVD players. The SL2309SI-1HT is a reliable and cost-effective solution for generating clock signals in a wide range of electronic systems.
