Products specifications

Category Sensors, Transducers>Motion Sensors - IMUs (Inertial Measurement Units)
Mfr STMicroelectronics
Series iNEMO
Package Tray
Product Status Obsolete
Sensor Type Accelerometer, Magnetometer, Temperature, 6 Axis
Output Type I2C, SPI
Temperature Range - Operating -40°C ~ 85°C (TA)
Package / Case 28-TFLGA Module
Supplier Device Package 28-LGA (7.5x4.4)
Mounting SMD (SMT)
Base Product Number LSM320
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN OBSOLETE
HTSUS 8542.39.0001
Standard Package 490
Win Source Part Number 997299-LSM320DL
Ultra Librarian 3D Model Ultra Librarian LSM320DL CAD Model

Description

The LSM320DL from STMicroelectronics is a state-of-the-art motion sensor that combines a 3D digital linear acceleration sensor and a 3D digital angular rate sensor into one compact unit. This advanced microelectromechanical system (MEMS) device is designed to cater to the growing demands of the mobile and gaming industries, as well as applications in industrial and medical instrumentation.

Key Features

  • High Precision: The LSM320DL offers high-resolution measurement of linear acceleration and angular rate with a 16-bit data output, ensuring precise motion detection and tracking.
  • Wide Range: It features selectable full scales for acceleration (±2/±4/±8/±16 g) and angular rate (±250/±500/±2000 dps), making it adaptable to various application requirements.
  • Embedded Intelligence: The sensor includes smart features such as a FIFO (First In, First Out) buffer, programmable interrupt generators for motion detection, and a sleep-to-wake-up function, enhancing system efficiency and extending battery life in portable devices.
  • Power Efficiency: The LSM320DL is designed for power-sensitive applications. It operates within a supply voltage range of 2.4 V to 3.6 V and includes power-down modes to conserve energy when not in active use.
  • Robust Design: It is built to withstand high shock survivability, making it reliable for use in harsh environments and situations where it may be subject to rough handling or vibrations.

Applications

The versatility of the LSM320DL allows it to be integrated into a wide array of applications, including:

  • Smartphones and tablets for screen orientation, gaming, and step counting.
  • Navigation systems and drones for accurate motion tracking and control.
  • Health and fitness trackers for monitoring activity and providing feedback.
  • Industrial systems for predictive maintenance and condition monitoring.
  • Medical devices for patient activity and posture detection.

Technical Support and Resources

STMicroelectronics provides comprehensive technical support for the LSM320DL, including detailed datasheets, application notes, and development tools to facilitate integration and accelerate product development. For more information, visit the STMicroelectronics website or contact their support team.
