STMicroelectronics M24C02-WBN6P EEPROM

The M24C02-WBN6P is a 2-Kbit serial EEPROM manufactured by STMicroelectronics, designed for flexible, non-volatile storage solutions in a wide array of electronic applications. This particular EEPROM device utilizes the I²C communication protocol, making it an excellent choice for systems that require efficient data transfer with minimal pin usage.

Key Features

• Memory Size: The device offers 2 Kbits of memory, which is organized as 256 x 8 bits. This capacity is ideal for storing configuration parameters, calibration data, or small application-specific data sets.
• I²C Interface: It supports a bidirectional two-wire bus and data transmission speeds of up to 400 kHz, ensuring compatibility with the standard I²C protocol and facilitating easy integration into existing systems.
• Write Cycle Time: The M24C02-WBN6P boasts a fast write cycle time of 5 ms (max), allowing for quick data updates and minimal downtime for the host system.
• Wide Operating Voltage Range: The device operates across a voltage range of 2.5 V to 5.5 V, making it versatile for different power supply environments.
• Endurance: It offers a high write endurance of 1 million write cycles per byte, along with a data retention period of 40 years, ensuring reliability and longevity of the stored data.
• Package: The EEPROM comes in a narrow 8-pin plastic DIP package, which is a popular choice for through-hole mounting, providing a robust physical connection suitable for various PCB designs.

Applications

The M24C02-WBN6P is widely used in applications such as:

• Consumer electronics
• Mobile devices
• Medical devices
• Industrial controls
• PC peripherals
• Smart cards

This EEPROM is a reliable choice for designers who require a small, yet efficient non-volatile memory solution. Its compatibility with the I²C bus system ensures that it can be easily integrated into a multitude of electronic systems without the need for complex wiring or additional components. The M24C02-WBN6P is a testament to STMicroelectronics' commitment to providing high-quality, durable, and easy-to-use memory solutions for the electronics industry.
