The STB30N65M5 is a state-of-the-art power MOSFET device designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This device is part of the MDmesh™ M5 series, which is known for its outstanding efficiency and performance in high-voltage applications. The STB30N65M5 is specifically engineered to address the demanding requirements of modern power supply systems, making it an ideal choice for a wide range of power conversion applications.

Key Features

• High Voltage Rating: With a drain-source voltage (V_DS) of 650V, the STB30N65M5 is well-suited for applications that require high voltage operation.
• Low On-Resistance: The device has an ultra-low on-resistance (R_DS(on)) of 0.073 Ohm, which enhances its efficiency by minimizing conduction losses.
• MDmesh™ M5 Technology: Leveraging STMicroelectronics' innovative MDmesh™ M5 technology, the STB30N65M5 offers an optimal balance of low gate charge and low on-resistance, resulting in reduced switching losses.
• High dv/dt Capability: Its high dv/dt rating ensures reliable operation in fast-switching applications, making it suitable for high-frequency converters and SMPS (Switched-Mode Power Supplies).
• Improved Zener Ruggedness: The device is equipped with a Zener-protected gate, which enhances its robustness against overvoltage events.

Applications

The STB30N65M5's superior electrical characteristics make it an excellent choice for various applications, including:

• Switched-Mode Power Supplies (SMPS)
• LED Lighting Applications
• Welding Equipment
• Solar Inverters
• UPS Systems
• High-performance Power Converters

Quality and Reliability

STMicroelectronics is committed to providing products that meet the highest standards of quality and reliability. The STB30N65M5 is no exception, undergoing rigorous testing and quality control measures to ensure it meets the stringent requirements of the industry. Customers can trust in the consistent performance and longevity of this power MOSFET in their advanced electronic designs.
