STH170N8F7-2: A High-Efficiency Power MOSFET from STMicroelectronics

STMicroelectronics, a global semiconductor leader, presents the STH170N8F7-2, a robust and efficient N-channel Power MOSFET designed to deliver outstanding performance in a wide array of applications. This device is part of STMicroelectronics' STripFET F7 series, which is renowned for its low on-resistance and low gate charge, making it an ideal choice for high-efficiency power management tasks.

The STH170N8F7-2 boasts an impressive 80V drain-source voltage (V_DS), catering to scenarios that demand high voltage capabilities. Additionally, it can continuously sustain currents up to 120A, thanks to its exceptional current handling capacity. This feature ensures that the MOSFET can manage significant power without compromising on performance or reliability.

One of the key advantages of the STH170N8F7-2 is its low on-state resistance (R_DS(on)) of just 6.7 mΩ (max), which minimizes conduction losses and enhances overall efficiency. This low R_DS(on) is achieved through advanced silicon technology, which allows for a compact and effective device design.

In terms of switching performance, the STH170N8F7-2 excels with its fast switching speed and reduced gate charge, enabling high-frequency operation while keeping switching losses to a minimum. This makes it particularly suitable for applications such as DC/DC converters, motor drives, and power supply units where efficiency and speed are paramount.

The STH170N8F7-2 is also designed with ruggedness in mind. It features 100% avalanche tested durability, ensuring that it can withstand harsh operating conditions and provide reliable performance over its lifespan. Additionally, the MOSFET comes in an H2PAK-2 package, which offers excellent thermal performance and is suitable for use in space-constrained environments.

Overall, the STH170N8F7-2 from STMicroelectronics is a top-tier component for designers looking to enhance power efficiency and reliability in their electronic designs. Its combination of low on-resistance, high current capability, and fast switching performance make it a versatile and dependable choice for a broad range of power applications.
