The STL13N60M2 is a high-performance, N-channel Power MOSFET presented by STMicroelectronics, renowned for its cutting-edge semiconductor solutions. This product is a testament to ST's commitment to offering energy-efficient and robust components for a wide array of power applications. The STL13N60M2 is designed to meet the rigorous demands of modern electronic circuits, providing a perfect blend of low on-resistance and high switching performance.

Key Features

• Drain-source Voltage (V<sub>DS): The STL13N60M2 can handle a maximum drain-source voltage of 600V, making it suitable for high voltage applications.
• Continuous Drain Current (I<sub>D): It offers a continuous drain current of 13A, ensuring high current handling capability.
• Low On-Resistance (R<sub>DS(on)): The MOSFET boasts an extremely low on-resistance of typically 0.280 ohms, contributing to its high efficiency and reduced power losses.
• Fast Switching Speed: It is designed for fast switching, which is crucial for reducing switching losses and improving power efficiency in applications such as switching regulators and converters.
• 100% Avalanche Tested: This device is guaranteed to be avalanche tested, ensuring reliability and robustness in harsh conditions.
• Enhanced Body Diode: The STL13N60M2 incorporates an enhanced body diode with a low reverse recovery time, which is beneficial in applications that require a fast diode.

Applications

Due to its exceptional features, the STL13N60M2 is well-suited for a broad range of high-efficiency applications, including but not limited to:

• Switch Mode Power Supplies (SMPS)
• LED Lighting
• DC-AC Inverters for Solar Energy Systems
• Uninterruptible Power Supplies (UPS)
• High-Performance Drives
• Power Factor Correction Circuits

The STL13N60M2 is available in a TO-220 package, which is widely accepted for commercial and industrial applications due to its ease of installation and thermal efficiency. With its robust design and high reliability, the STL13N60M2 from STMicroelectronics stands as a solid choice for designers looking to enhance system performance while maintaining energy efficiency and thermal management.
