STM8S003F3P6TR Microcontroller by STMicroelectronics

The STM8S003F3P6TR is a robust and versatile 8-bit microcontroller from STMicroelectronics, designed to deliver high performance and efficiency in a wide range of embedded applications. This particular MCU is part of the STM8S Value Line, which is known for providing cost-effective solutions without compromising on quality or features.

At the heart of the STM8S003F3P6TR is a high-performance STM8 core operating at up to 16 MHz. It comes with 8 KB of Flash program memory, which is more than adequate for many simple applications, and 1 KB of RAM, ensuring smooth operation. The device also includes 128 bytes of EEPROM, which is particularly useful for storing non-volatile data that must be preserved between resets or power cycles.

The microcontroller includes an array of peripherals that enhance its capabilities. These include:

• Integrated true data EEPROM
• Advanced control timer
• USART communication interface
• SPI and I2C interfaces for serial communication
• 10-bit ADC with multiple channels
• Internal and external clock options with PLL
• Watchdog and brown-out reset for system reliability

The STM8S003F3P6TR operates within a supply voltage range of 2.95 V to 5.5 V, making it suitable for both battery-powered and mains-powered applications. Its temperature range from -40°C to 85°C ensures reliable operation even in harsh environments.

STMicroelectronics has equipped the STM8S003F3P6TR with robust I/Os that are 5V tolerant, providing a degree of flexibility and protection in mixed-voltage environments. The MCU is available in a TSSOP20 package, which is ideal for space-constrained applications.

With its combination of performance, peripherals, and power efficiency, the STM8S003F3P6TR is an excellent choice for projects ranging from simple control systems to more complex automation tasks. Its cost-effectiveness makes it particularly attractive for mass-market product designs where keeping the bill of materials low is crucial.

STMicroelectronics also provides comprehensive development tools and software libraries to support the STM8S family, making it easier for engineers to bring their products to market quickly and efficiently.
