The STMUX1800LQTR is a high-performance, low-voltage, 8-channel analog switch from STMicroelectronics, designed to deliver exceptional signal integrity and flexibility for a wide range of applications. This advanced switch is housed in a compact QFN-24L 4x4 package, making it ideal for space-constrained applications.

Key Features

• Wide Voltage Range: The device operates with a supply voltage ranging from 1.8V to 5.5V, accommodating various logic levels and allowing for integration in mixed-voltage systems.
• Low On-Resistance: With a typical on-resistance of just 4 ohms, the STMUX1800LQTR ensures minimal signal distortion and power loss, enhancing overall system efficiency.
• High Current Handling: Each channel can handle continuous current up to 300 mA, making this switch suitable for high-current applications.
• ESD Protection: The device features built-in ESD protection, safeguarding the switch against electrostatic discharges and ensuring long-term reliability.
• Break-Before-Make Switching: This functionality prevents momentary short circuits when switching between channels, preserving signal integrity and preventing damage to downstream components.

Applications

The STMUX1800LQTR is versatile and can be used in numerous applications, including:

• Data acquisition systems
• Signal routing in audio and video equipment
• Communication systems
• Medical equipment
• Industrial process control

Quality and Reliability

STMicroelectronics is renowned for its commitment to quality, and the STMUX1800LQTR is no exception. It is manufactured using a robust process that ensures high reliability and performance over its entire operating temperature range of -40°C to 85°C. With its comprehensive set of features and reliable performance, the STMUX1800LQTR is an excellent choice for designers looking to enhance the flexibility and efficiency of their electronic systems.
