NLV25T-3R9J-PFD Real Image
Same model may have multiple batches, images only for reference.

NLV25T-3R9J-PFD

Part No NLV25T-3R9J-PFD
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 3.9UH 180MA 2.1 OHM / Inductor General Purpose Chip Molded/Unshielded Wirewound 3.9uH 5% 7.96MHz 30Q-Factor Ferrite 0.18A 2.1Ohm DCR 1008 Automotive T/R
Datasheet
NLV25T-3R9J-PFD Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Series NLV-PFD
Packaging Reel package
Type Wirewound
Material - Core Ferrite
Inductance 3.9μH
Tolerance ±5%
Current Rating 180mA
Shielding Unshielded
DC Resistance (DCR) 2.1 Ohm Max
Q @ Freq 30 @ 7.96MHz
Frequency - Self Resonant 48MHz
Ratings AEC-Q200
Operating Temperature Range -40°C ~ 105°C
Test Frequency 7.96MHz
Mounting SMD
Package 1008 (2520 Metric)
Manufacturer Package 1008 (2520 Metric)
Dimension 0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Maximum) 0.075" (1.90mm)
Win Source Part Number 790730-NLV25T-3R9J-PFD
Popularity Medium
Supply and Demand Status Balance
Quantity per package 2k pcs
Family Name NLV-PFD
ECCN EAR99
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian NLV25T-3R9J-PFD CAD Model

Description

The TDK Corporation NLV-PFD series wirewound inductor is a high-quality electronic component that is designed to provide reliable performance in a range of applications.

  • Operating Temperature Range: -40°C to 105°C
  • Package: 1008 (2520 Metric)
  • Current Rating: 180mA
  • Inductance: 3.9μH
  • Mounting: SMD
  • Tolerance: ±5%
  • AEC-Q200 Rated: Yes
  • Core: Ferrite
  • Q @ Freq: 30 @ 7.96MHz
  • Frequency - Self-Resonant: 48MHz
  • DC Resistance (DCR): 2.1 Ohm Max
  • Dimension: 0.098" L x 0.079" W (2.50mm x 2.00mm)
  • Height: 0.075" (1.90mm)
  • Quantity Per Package: 2k pcs
