ICM-20602 Real Image ICM-20602 real image23262 ICM-20602 real image23263 ICM-20602 Real Image1 ICM-20602 Real Image2 ICM-20602 Real Image3 ICM-20602 Real Image4 ICM-20602 Real Image5
Same model may have multiple batches, images only for reference.
ICM-20602 Real Image ICM-20602 real image23262 ICM-20602 real image23263 ICM-20602 Real Image1 ICM-20602 Real Image2 ICM-20602 Real Image3 ICM-20602 Real Image4 ICM-20602 Real Image5
ICM-20602 Real Image ICM-20602 real image23262 ICM-20602 real image23263 ICM-20602 Real Image1 ICM-20602 Real Image2 ICM-20602 Real Image3 ICM-20602 Real Image4 ICM-20602 Real Image5
Same model may have multiple batches, images only for reference.

ICM-20602

Part No ICM-20602
Manufacturer TDK InvenSense
Catalog Motion Sensors - IMU (Inertial Measurement Units)
Description IMU ACCEL/GYRO/TEMP I2C/SPI LGA / Accelerometer, Gyroscope, Temperature, 6 Axis Sensor I2C, SPI Output
Datasheet
ICM-20602 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Motion Sensors - IMUs (Inertial Measurement Units)
Mfr TDK InvenSense
Package Tape & Reel
Product Status Not For New Designs
Sensor Type Accelerometer, Gyroscope, Temperature, 6 Axis
Output Type I2C, SPI
Temperature Range - Operating -40°C ~ 85°C (TA)
Package / Case 16-WFLGA Module
Supplier Device Package 16-LGA (3x3)
Mounting Type Surface Mount
Standard Package 5,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 7A994
HTSUS 8542.39.0001
Win Source Part Number 825423-ICM-20602
Ultra Librarian 3D Model Ultra Librarian ICM-20602 CAD Model

Description

The ICM-20602 is a motion sensor IMU (Inertial Measurement Unit) designed for various applications.

  • Sensor Type: 6-axis (Accelerometer and Gyroscope) with Temperature Sensor
  • Mounting Type: Surface Mount
  • Package: 16-WFLGA Module
  • Supplier Device Package: 16-LGA (3x3)
  • Operating Temperature: -40°C to 85°C
  • Output Type: I2C, SPI
  • Manufacturer: TDK InvenSense
