166292-1 TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

166292-1

Part No 166292-1
Manufacturer TE Connectivity
Catalog D - Sub, D - Shaped Connectors - Contacts
Description CONN D-SUB SOCKET 24-28 AWG CRMP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Signal
Contact Type Female Socket
Contact Form Stamped
Wire Gauge 24-28 AWG
Contact Termination Crimp
Contact Material Phosphor Bronze
Contact Finish Gold
Contact Finish Thickness 30.0µin (0.76µm)
Termination Finish Tin
Contact Size 20
Features Insulation Support
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1622445-166292-1
Ultra Librarian 3D Model Ultra Librarian 166292-1 CAD Model

Description

N
