The TE Connectivity AMP Connectors 1332582-6-146257-0 is a header, breakaway connector with a copper alloy contact material.

• Pitch-Mating: 0.100" (2.54mm)
• Row Spacing-Mating: 0.100" (2.54mm)
• Number of Positions Loaded: all
• Number of Rows: 2
• Contact Type: male pin
• Fastening Type: push-pull
• Termination: solder
• Insulation Material: liquid crystal polymer (LCP)
• Insulation Height: 0.090" (2.29mm)
• Contact Shape: square
• Contact Length-Post: 0.120" (3.05mm)
• Overall Contact Length: 0.440" (11.18mm)
• Contact Length-Mating: 0.230" (5.84mm)
• Contact Finish-Mating: gold
• Contact Finish Thickness-Mating: 30.0µin (0.76µm)
• Contact Finish-Post: tin
• Contact Finish Thickness-Post: 100.0µin (2.54µm)
• Current Rating: 3A
• Temperature Range: -65°C ~ 105°C
• ROHS3 Compliant: Yes
• Standard Package: 4,000
• Base Product Number: 146257
