ADS1251U/2K5 Real Image ADS1251U/2K5 real image ADS1251U/2K5 Real Image
ADS1251U/2K5 Real Image ADS1251U/2K5 real image ADS1251U/2K5 Real Image
Same model may have multiple batches, images only for reference.

ADS1251U/2K5

Part No ADS1251U/2K5
Manufacturer Texas Instruments
Catalog Data Acquisition - Analog to Digital Converters (ADC)
Description 1-Channel Single ADC Delta-Sigma 20ksps 24-bit Serial 8-Pin SOIC T/R / IC ADC CONV 24BIT LP 8-SOIC
Datasheet
ADS1251U/2K5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Number of Bits 24
Sampling Rate 20k
Number of Inputs 1
Input Type Differential
Data Interface SPI
Configuration ADC
Number of A/D Converters 1
Reference Type External
Analog Supply Voltage 5V
Digital Supply Voltage 5V
Temperature Range - Operating -40°C to 85°C
Case / Package 8-SOIC
Win Source Part Number 009272-ADS1251U/2K5
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name ADS1251
Introduction Date June 01, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ADS1251U/2K5 CAD Model

Description

ADS1251U/2K5

The ADS1251U/2K5 combines high accuracy with low power consumption, making it an optimal solution for precision analog data acquisition in both stationary and portable systems.

  • Portable Instrumentation
  • Digital Weighing Scales
  • Process Control Systems

Features and Benefits:

  • Optimized for high resolution and low drift.
  • Flexible input range for various sensor types.
  • Enhanced noise performance for clear data interpretation.

Additional Details:

The device is engineered to deliver outstanding performance in noise-sensitive applications. Its compact design allows for easy implementation in space-constrained environments.
