CSD18532Q5BT

Part No CSD18532Q5BT
Manufacturer Texas Instruments
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 23A 8VSON / Trans MOSFET N-CH Si 60V 100A 8-Pin VSON-CLIP EP T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Texas Instruments
Series NexFET
Packaging Reel package
Channel Type Type N
Technology MOSFET
Drain Source Voltage 60V
Current - Continuous Drain (Id) @ 25°C 100A (Ta)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Vgs(th) (Maximum) @ Id 2.2V @ 250μA
Gate Charge (Qg) (Maximum) @ Vgs 58nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds 5070pF @ 30V
Vgs (Maximum) ±20V
Power Dissipation (Maximum) 3.2W (Ta), 156W (Tc)
Rds On (Maximum) @ Id, Vgs 3.2 mOhm @ 25A, 10V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting SMD
Manufacturer Package 8-VSON (5x6)
Package 8-PowerTDFN
Win Source Part Number 771874-CSD18532Q5BT
Popularity Medium
Supply and Demand Status Limited
Family Name CSD18532Q5B
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian CSD18532Q5BT CAD Model

Description

Introducing the CSD18532Q5BT from Texas Instruments

The CSD18532Q5BT is a state-of-the-art N-Channel NexFET™ power MOSFET brought to you by Texas Instruments, designed to deliver high efficiency and power density with reduced power losses. This cutting-edge component is a perfect solution for a wide range of applications, including power supply, battery management, and DC-DC conversion systems.

Key Features

  • Low On-Resistance: With a typical RDS(on) of just 2.5 mΩ, this MOSFET minimizes conduction losses, making it ideal for high-efficiency power designs.
  • High Continuous Drain Current: It supports a robust continuous drain current (ID) of 100 A, ensuring reliable performance for demanding applications.
  • Advanced Thermal Performance: The CSD18532Q5BT is encapsulated in a compact VSON package with an exposed thermal pad, providing excellent thermal management.
  • Fast Switching Speed: Its optimized gate charge (Qg) and low input capacitance (Ciss) contribute to fast switching speeds, reducing switching losses.

Applications

The versatility of the CSD18532Q5BT allows it to be utilized across a diverse set of applications, including:

  • Telecom and server power supplies
  • Industrial power supplies
  • Motor control circuits
  • Battery-powered systems
  • DC-DC converters
  • Load switches

Quality and Reliability

As with all Texas Instruments products, the CSD18532Q5BT is manufactured to meet high-quality standards. It undergoes rigorous testing to ensure reliability and performance under various conditions. Customers can trust this MOSFET to provide long-term stability and efficiency in their electronic designs.

Environmental Considerations

The CSD18532Q5BT is RoHS compliant, reflecting Texas Instruments' commitment to environmental sustainability. By adhering to these standards, TI ensures that the product is free of hazardous substances, making it a responsible choice for both manufacturers and the environment.

For detailed technical specifications, application notes, and support resources, visit the Texas Instruments website or contact their support team. The CSD18532Q5BT represents TI's dedication to innovation, offering designers a powerful component that enhances the performance of their electronic products.
