The Texas Instruments DRV8812RHDR is a state-of-the-art motor driver IC designed for precision control of bipolar stepper motors. This robust and versatile driver is an ideal solution for a wide range of applications including printers, scanners, office automation machines, and robotics. With advanced features and a compact form factor, the DRV8812RHDR makes it easy to implement sophisticated motor control systems.

Key Features

• Dual H-Bridge Motor Driver: Capable of driving two DC motors or one stepper motor, the DRV8812RHDR offers flexibility for various design needs.
• High Output Drive Capability: With output current capability of up to 1.6 A per channel and operating voltage range from 8.2 V to 45 V, this driver can handle a broad spectrum of motor specifications.
• Microstepping Support: The device supports up to 1/32-step microstepping, providing fine control over motor movements for precise positioning applications.
• Integrated Protection Features: The DRV8812RHDR includes multiple protection features such as overcurrent, thermal shutdown, and under-voltage lockout, ensuring reliable operation and longevity of the motor and the driver.
• Configurable Decay Modes: Users can select from slow, fast, or mixed decay modes, allowing for optimization of motor performance and power efficiency.

Technical Specifications

Parameter Value Output Current (max) 1.6 A Operating Voltage Range 8.2 V to 45 V Microstepping Resolution Up to 1/32-step Protection Features Overcurrent, Thermal Shutdown, UVLO Package VQFN (32)

Applications

The DRV8812RHDR is suitable for a variety of applications where precise motor control is essential. Its high level of integration and comprehensive feature set make it a go-to choice for developers in the fields of automation, consumer electronics, and industrial systems.

For more detailed information, including datasheets, design resources, and ordering options, please visit the Texas Instruments official website or contact your local TI distributor.
