The EVM430-FE4272 from Texas Instruments is a robust evaluation module designed for engineers, developers, and enthusiasts to expedite the development and testing of power measurement systems. This evaluation module is specifically designed to work with the MSP430FE4272 microcontroller, a highly integrated device optimized for electronic metering applications that require measurements with high accuracy and low-power consumption.

Key Features

• Integrated MSP430 Microcontroller: At the heart of the EVM430-FE4272 is the MSP430FE4272 microcontroller, which features a 16-bit RISC CPU, 16KB + 256B Flash memory, and 512B RAM.
• Energy Measurement: The module is equipped with a 24-bit sigma-delta analog-to-digital converter (ADC) for high-precision energy measurement, making it ideal for applications such as smart metering and energy monitoring.
• On-Board LCD: A built-in LCD display allows for immediate visualization of data and measurements without the need for additional components.
• Flexible Power Supply: The EVM430-FE4272 can be powered through USB or an external power supply, providing versatility for different testing scenarios.
• Comprehensive Development Tools: Texas Instruments provides a suite of software tools and libraries to support the development process, including code examples and application notes.

Applications

The EVM430-FE4272 is suitable for a wide range of applications that require precise energy measurement and low-power operation. These include:

• Smart electricity meters
• Power monitoring systems
• Renewable energy systems
• Industrial metering

Technical Specifications

The module comes with the following technical specifications:

• Supply voltage: 2.2V to 3.6V
• Operating temperature: -40°C to 85°C
• Dimensions: 100mm x 50mm

With its combination of precision, flexibility, and ease of use, the EVM430-FE4272 is an excellent tool for developing and prototyping energy measurement solutions.
