Product Overview: INA180A2IDBVT from Texas Instruments

The INA180A2IDBVT is a high-precision current sense amplifier from Texas Instruments, designed to provide a comprehensive solution for current monitoring in a variety of applications. This versatile component is part of the INA180 series, which is renowned for its accuracy, low power consumption, and ease of use.

Key Features

• Supply Voltage Range: The INA180A2IDBVT operates over a supply voltage range of 2.7V to 5.5V, making it suitable for both 3.3V and 5V systems.
• Gain Options: This device offers a fixed gain of 20V/V, which simplifies the design process by eliminating the need for external gain-setting components.
• Low Quiescent Current: It features a low quiescent current of only 260µA (typical), which is ideal for battery-powered and energy-efficient applications.
• Common-Mode Range: The INA180A2IDBVT boasts a wide common-mode range that extends from -0.2V to +26V, allowing for versatile use in systems with varying ground potentials.
• High Accuracy: Precision engineering ensures high accuracy in current measurement, which is critical for system performance and reliability.
• Small Package: Available in a small, surface-mount SOT-23 package, this current sense amplifier is perfect for space-constrained applications.

Applications

The INA180A2IDBVT is well-suited for a wide range of applications, including but not limited to:

• Power management in portable devices
• Battery chargers and management systems
• Overcurrent protection circuits
• Automotive and industrial systems monitoring
• Energy metering and power supply monitoring

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the INA180A2IDBVT is no exception. It is designed and manufactured to meet the highest standards, ensuring reliable performance in even the most demanding environments.

In summary, the INA180A2IDBVT from Texas Instruments is an optimal choice for designers looking for a high-accuracy, low-power current sense amplifier that is both easy to implement and versatile for various applications.
