Product Overview: INA213AIDCK from Texas Instruments

The INA213AIDCK is a high-precision voltage output, current shunt monitor from Texas Instruments, designed to provide industry-leading performance for accurate current measurement in a variety of applications. This device is part of TI's extensive family of current sense amplifiers that offer a solution for applications requiring low cost, high precision, and small size.

Key Features

• High Accuracy: With an impressive gain error of only ±0.2%, the INA213AIDCK ensures precise current measurement, making it ideal for demanding applications where accuracy is critical.
• Wide Common-Mode Range: The device operates over a common-mode voltage range from -0.3V to 26V, which is suitable for various systems, including those with higher voltage rails.
• Low Quiescent Current: It features a low quiescent current of 100 μA (typical), which is beneficial for power-sensitive applications.
• Configurable Gain: The INA213AIDCK offers a set gain of 200V/V, which simplifies the design process by eliminating the need for external gain-setting components.
• Small Package: Available in a SC-70 package, this current shunt monitor is designed for space-constrained applications.

Applications

The INA213AIDCK is versatile and can be used in various applications, including:

• Battery chargers
• Portable devices
• Power management
• Overcurrent protection
• Automotive systems

Reliability and Performance

With Texas Instruments' commitment to quality and performance, the INA213AIDCK is manufactured to meet high standards of reliability. It is designed to operate over the extended industrial temperature range of -40°C to +125°C, ensuring consistent performance across a wide range of operating conditions.

Design Support

Texas Instruments provides comprehensive design resources, including datasheets, reference designs, and simulation tools, to assist engineers in integrating the INA213AIDCK into their projects. This support helps to streamline the design process and reduce time to market for products incorporating this advanced current shunt monitor.
