LM1086ISX-3.3/NOPB Texas Instruments LM1086ISX-3.3/NOPB Real Image LM1086ISX-3.3/NOPB real image LM1086ISX-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.
LM1086ISX-3.3/NOPB Texas Instruments LM1086ISX-3.3/NOPB Real Image LM1086ISX-3.3/NOPB real image LM1086ISX-3.3/NOPB Real Image
LM1086ISX-3.3/NOPB Texas Instruments LM1086ISX-3.3/NOPB Real Image LM1086ISX-3.3/NOPB real image LM1086ISX-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.

LM1086ISX-3.3/NOPB

Part No LM1086ISX-3.3/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 3.3V 1.5A 4-Pin(3+Tab) DDPAK T/R / IC REG LDO 3.3V 1.5A DDPAK
Datasheet
LM1086ISX-3.3/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 27V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.5V @ 1.5A
Output Current 1.5A
Operating Supply Current 5mA to 10mA
PSRR 72dB (120Hz)
Control Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.3V @ 1.5A
Mounting SMD (SMT)
Case / Package DDPAK/TO-263-3
Win Source Part Number 018640-LM1086ISX-3.3/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name LM1086
Introduction Date August 01, 1999
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LM1086ISX-3.3/NOPB CAD Model

Description

The LM1086ISX-3.3/NOPB is a high-performance, low-dropout voltage regulator from Texas Instruments, a renowned name in the semiconductor industry.

  • Output Voltage: 3.3V
  • Output Current: 1.5A
  • Input Voltage Range: 2.5V to 18V
  • Dropout Voltage: 1.5V @ maximum output
  • Output Voltage Accuracy: 1%
  • Line and Load Regulation: Excellent
  • Safety Features: Current limiting and thermal shutdown
  • Package: TO-263
  • RoHS Compliant: Yes
