LM1117DT-3.3 Texas Instruments LM1117DT-3.3 real image941 LM1117DT-3.3 Real Image1 LM1117DT-3.3 Real Image2 LM1117DT-3.3 Real Image3 LM1117DT-3.3 Real Image4 LM1117DT-3.3 real image
Same model may have multiple batches, images only for reference.
LM1117DT-3.3 Texas Instruments LM1117DT-3.3 real image941 LM1117DT-3.3 Real Image1 LM1117DT-3.3 Real Image2 LM1117DT-3.3 Real Image3 LM1117DT-3.3 Real Image4 LM1117DT-3.3 real image
LM1117DT-3.3 Texas Instruments LM1117DT-3.3 real image941 LM1117DT-3.3 Real Image1 LM1117DT-3.3 Real Image2 LM1117DT-3.3 Real Image3 LM1117DT-3.3 Real Image4 LM1117DT-3.3 real image
Same model may have multiple batches, images only for reference.

LM1117DT-3.3

Part No LM1117DT-3.3
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 3.3V 0.8A 3-Pin(2+Tab) TO-252 Rail / IC REG LDO 3.3V 0.8A TO252-3
Datasheet
LM1117DT-3.3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 15V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 1.2V @ 800mA
Output Current 800mA
Operating Supply Current 5mA to 10mA
PSRR 75dB (120Hz)
Control Protection Features Over Current, Over Temperature
Temperature Range - Operating 0°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 1.2V @ 800mA
Mounting SMD (SMT)
Case / Package TO-252-3
Win Source Part Number 206280-LM1117DT-3.3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Power Management
Family Name LM1117
Introduction Date June 01, 1998
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian LM1117DT-3.3 CAD Model

Description

The LM1117DT-3.3 is a low-dropout linear voltage regulator from Texas Instruments, a global semiconductor design and manufacturing company.

  • Load Current: 800mA
  • Dropout Voltage: 1.2V
  • Output Voltage: 3.3V
  • Output Voltage Deviation: maximum of 2%
  • Features: built-in thermal and current limit circuits
  • Package: TO-252 package (DPAK)
